2.8mm endoscope camera Module
| Module No. | AMC0115USB-D2.8 |
| Module Size | 2.8mm dia * L10mm(metal tube) |
| Object distance | 3-50mm (105DFOV) |
| Focus | Fixed Focus |
| Image quality | Colorful |
| Audio | no microphone |
| Interface | USB 2.0 |
| Voltage | DC 5V |
| Temperature (Operation) | 0°C to 70°C |
| Temperature (Stable Image) | 0°C to 50°C |
| Waterproof | IP67 Waterproof |
| Operating system request | Windows, Linux, macOS |
| Sensor Type | |
| Sensor No. | / |
| Sercor Type | 1/15″ |
| Active Array Size | 240H*320V |
| Pixel Size | 1.4μm x 1.4μm |
| Resolution @ Frame Rate | MJPEG: 240*320@30fps
YUY2: 240*320@30fps
|
| Wide Dynamic Range | / |
| LENS | |
| FOV | D=105°, F.N0=4.5 |
| IR Filter | 650±10nm |
| Distortion | <5% |
| LED | |
| LED | 4pcs LEDs |
| DSP Type | |
| GC/EC/Whiter balance | Auto |
| Output Formats | YUV/MJPG |
Specification:
- 1/15 inch
- IP67 waterproof
- 105DFOV
- suggested DOF is 3-50mm
- MIPI Cable 0-1.5 meters
- Designed for medical
- 2.8mm dia* 10mm metal tube
- 240*320 resolution, portrait image direction
- High-quality image
- UVC compliant, Plug & Play
- Support USB2.0 OTG
You can check the image effect of 2.8mm endoscope in the video below.
2.8mm Endoscope Module Details
image effect of 2.8mm endoscope module
portrait image direction, 240*320
plug and play, UVC, Driver free
This module is an old version, but the image effect is the same as below.
