Revolutionary Features
🎯 Advanced Stereo Vision
- Dual 5MP Sensors: Twin high-resolution sensors for accurate depth perception
- Stereo Baseline: Optimized lens spacing for precise depth calculation
- 3D Mapping: Real-time depth map generation with sub-millimeter accuracy
- Parallax Processing: Advanced algorithms for seamless stereo image fusion
🌈 HDR Imaging Excellence
- High Dynamic Range: Captures details in both bright and dark areas simultaneously
- Multi-exposure Fusion: Combines multiple exposures for optimal image quality
- Enhanced Color Reproduction: Vivid and accurate color representation
- Noise Reduction: Advanced algorithms minimize noise in challenging lighting conditions
💡 Dual Spectrum Capability
- 850nm Infrared: Near-infrared imaging for low-light and night vision applications
- Full Color Spectrum: True-to-life color reproduction in visible light
- Automatic Mode Switching: Seamless transition between color and IR modes
- Simultaneous Capture: RGB and IR image capture for comprehensive analysis
🔌 USB Connectivity & Control
- USB 3.0 SuperSpeed: High-bandwidth data transfer for dual 5MP streams
- Plug & Play: UVC compliant, no driver installation required
- Cross-Platform Support: Compatible with Windows, Linux, MacOS, and Android
- Real-time Streaming: Synchronized dual-camera live video streaming
Technical Specifications
| Specification | Details |
|---|---|
| Image Sensor | Dual 5MP CMOS Sensors |
| Maximum Resolution | 2592×1944 per lens |
| Frame Rate | 30fps@1080p, 15fps@5MP |
| Interface | USB 3.0 SuperSpeed |
| IR Wavelength | 850nm (Near Infrared) |
| Stereo Baseline | 65mm (adjustable models available) |
| Field of View | 75°(H) × 60°(V) per lens |
| Focus Range | 30cm to infinity |
| Depth Accuracy | ±2mm at 1 meter |
| HDR Range | 120dB dynamic range |
| Power Consumption | 5W max (USB powered) |
| Operating Voltage | 5V DC via USB |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +70°C |
| Humidity | 10-90% RH (non-condensing) |
| Dimensions | 95×25×15mm |
| Weight | 45g |
Advanced Capabilities
📐 Depth Sensing & Measurement
- Real-time Depth Maps: Generate accurate 3D depth information
- Distance Measurement: Precise object distance calculation
- Volume Estimation: Calculate object dimensions and volumes
- Surface Analysis: Detect surface irregularities and textures
🤖 AI-Ready Processing
- Object Detection: Enhanced 3D object recognition capabilities
- Gesture Recognition: Advanced hand and body gesture tracking
- Facial Recognition: 3D facial analysis with anti-spoofing
- Motion Tracking: Accurate movement detection and analysis
🎥 Professional Imaging
- Synchronized Capture: Perfect frame synchronization between lenses
- Exposure Control: Independent or synchronized exposure settings
- White Balance: Automatic or manual white balance adjustment
- Image Stabilization: Digital stabilization for smooth video capture
Application Scenarios
🏭 Industrial Automation
- Quality Inspection: Precise dimensional measurement and defect detection
- Robotic Vision: Advanced guidance for industrial robots
- Assembly Line Monitoring: Real-time production quality control
- 3D Scanning: High-accuracy 3D model generation
🚗 Automotive & Transportation
- Advanced Driver Assistance: Depth-aware collision avoidance systems
- Parking Assistance: Accurate distance measurement for parking
- Traffic Analysis: Vehicle counting and speed detection
- Fleet Management: Driver behavior monitoring and analysis
🏥 Medical & Healthcare
- Surgical Navigation: Precise 3D guidance for medical procedures
- Patient Monitoring: Non-contact vital sign detection
- Rehabilitation: Motion analysis for physical therapy
- Diagnostic Imaging: Enhanced medical image analysis
🎮 Entertainment & Gaming
- Motion Capture: Full-body motion tracking for gaming
- Augmented Reality: Accurate environment mapping for AR applications
- Virtual Reality: Precise hand and object tracking
- Interactive Displays: Gesture-controlled interfaces
🔬 Research & Development
- Computer Vision Research: Advanced stereo vision algorithms development
- Robotics: Visual SLAM and navigation systems
- Scientific Analysis: Precise measurement and documentation
- Educational Projects: STEM learning and experimentation
