10x optical zoom camera is for video meeting, education, security or other devices.
| Module No. | 179-OZ-V1.0 |
| Module Size | 64*35*38mm |
| Weigth | 57.2g |
| Object distance | Wide: 0.1m~INF
Tele: 1.0m~INF |
| Focus | 10x Optical Zoom, Motorized |
| Image quality | Colorful |
| Audio | no microphone/ 1pc microphones |
| Interface | USB 2.0 |
| Voltage | DC 5V |
| Temperature (Operation) | -30°C to 70°C |
| Temperature (Stable Image) | 0°C to 50°C |
| Operating system request | WinXP/Vista/Windows 7 (32bit/64bit)/Windows 8/Windows 10/MAC OSX EI captain 10.11.4 and Linux /Android |
| Sensor Type | |
| Sensor No. | IMX179 SONY 8mp |
| Sercor Type | 1/3.2″ |
| Active Array Size | 3264H*2448V |
| Pixel Size | 1.4μm x 1.4μm |
| Resolution @ Frame Rate | MJPEG:
3264*2448@20fps 2592*1944@20fps 1920*1080@30fps 1280*720@30fps 640*480@30fps
YUV: 3264*2448@2fps 2592*1944@2fps 1920*1080@3fps 1280*720@5fps 640*480@30fps |
| Wide Dynamic Range | / |
| LENS | |
| FOV | D=65° H=52° V=38°(Wide)
D=7° H=5° V=4° (Tele) |
| IR Filter | 4.9~49mm±5% （10x） |
| IR Filter | F3.4(Wide)~F3.8(Tele) ±5% |
| IR Filter | Wide: 0.1m~INF
Tele: 1.0m~INF |
| IR Filter | 650±10nm |
| IR Filter | 9 groups and 14 elements |
| Distortion | -1.2%~+0.8% |
| LED | |
| LED | no LEDs |
| DSP Type | |
| GC/EC/Whiter balance | Auto |
| Output Formats | YUV/MJPG |
Feature
* IMX179 8mp Sony Sensor
* USB2.0 5pin 1.00mm pitch
* 10x optical lens zoom camera module
* USB2.0 5pin 1.00mm pitch
* 10x optical lens zoom camera module
* motorized control by button
* There’s 1pc microphone for options
* designed for IOT, Education, Security
* High quality image
* UVC compliant, Plug & Play
* Support USB2.0 OTG
* There’s 1pc microphone for options
* designed for IOT, Education, Security
* High quality image
* UVC compliant, Plug & Play
* Support USB2.0 OTG
